Picket Railing: Series 9P

Centerfield Flats

Series 9P Picket Railing

Superior Series 9P Aluminum Picket Railing offers a reliable, modern design tailored to each project, saving time and money. Available in 2-line or 3-line styles with customizable features, this aluminum railing can be constructed at any height. Contact us to start your project or request a quote.

Complies with the following building codes:

  • OSHA
  • ADA
  • ICC

9P Picket Railing Features

Concealed Picket Screws

Screw covers hide unsightly fasteners on your top and bottom rail!

Pocket Posts

Machined posts tidy up your project by removing brackets on level applications!

Custom Applications

Projects can be fully customized to fit any need you may have!

Gallery

Series 9P Picket Railing Design Options

Standard Finishes – Always Available

WHITE

BLACK

DARK BRONZE

SANDSTONE

GRAY

SATIN ANODIZED

NOTE: Due to variations in individual monitor settings and calibrations, actual product colors may vary from those represented on this site. Color chip samples are available upon request – for more information, please contact us, or locate a representative.

Standard Dimensions

Top Rail

  • 2-inch
Pocketed Posts

  • 2.5-inch (standard)
  • 4-inch
Square Pickets

  • 3/4-inch (standard)
  • 1.5-inch

Styles

Style A
Standard

Style B
Open Double Top Rail

Style C
Double Top Rail with Through Picket

Documentation

3 Part Specification
Section 05 7300 Decorative Metal Railing

Series 9P Picket Railing: Stair Railing Kit Assembly Instructions

Series 9P Picket Railing: Level Railing Kit Assembly Instructions

Material Specifications

SERIES 9P, 9H, 7P, 7V, 6E

  • All rails, posts, and pickets shall be formed from 6063-T5, 6063-T52, 6063-T6, or 6005A-T61 extruded aluminum alloys depending on exact application.
  • All post reinforcement rods (where applicable) shall be formed from 6061-T6 extruded aluminum alloy.
  • All railing accessories shall be cast from industry standard aluminum alloys according to the requirements of the application.
  • All exposed fasteners used in the system shall be aluminum or stainless steel.
  • All PPG Duracron paint finishes and anodized finishes adhere to the specifications set forth by the American Architectural Manufacturers Association.
